Aseptic Tubing Welder 100
The Applitech Welder 100 is a fuly automatic device designed for aseptic connection of thermoplastic tubing used in single-use coextrusion bags or related processes. it enables aseptic connection of various tubing components, supporting multiple brands of empty or liquid-filled thermoplastic tubing, in both cleanroom and non-cleanroom environments.
The Applitech Welder 100 is a fuly automatic device designed for aseptic connection of thermoplastic tubing used in single-use coextrusion bags or related processes. it enables aseptic connection of various tubing components, supporting multiple brands of empty or liquid-filled thermoplastic tubing, in both cleanroom and non-cleanroom environments.
To operate, the tubing holders, blades, and the two tubing sections to be welded are placed into the corresponding positions in thedevice. By activating the system via the touchscreen, the blade is sterlized by heating and then automatically cooled to the weldingtemperature, Once ready, the blade cuts the tubing and thermally fuses the two sections together. Throughout the entire welding process,the blade remains sterile without acting as a heat source, ensuring aseptic operation.
Features
- 7-inch high-definition touchscreen for a more comfortable human-machine interaction.
- Fully automatic touchscreen operation with terminal automation control.
- Adjustable temperature profiles for blade heating and welding.
- Compatible with multiple brands of TPE tubing with outer diameters of 6.4-25.4 mm (1/4"_1").
- Infrared temperature sensor monitoring; blade heating exceeds 400'C for sterilization.
- Fully enclosed welding process to prevent contamination during cutting and welding
- Bottom drain port design for easy cleaning.
- Robust and stable cutting and welding unit to ensure safe tubing connection.
- Compliant with FDA 21 CFR Part 11, featuring user access control, audit trails, and data export.
- Provides a complete set of validation documents, including flow rate, insoluble particles, tensilestrength, pressure resistance, sterility, bacterial challenge, and blade compatibility validation
- Equipped with emergency stop button, over-temperature warning, and protection functions.
