AbioSealer M500
AbioSealer M500 supports the disconnection of thermoplastic tubes in non-sterile environments, maintaining the sterility of the product. It can be widely used for sealing thermoplastic tubes on various single-use bag or tube assembly, achieving aseptic disconnection.
AbioSealer M500 supports the disconnection of thermoplastic tubes in non-sterile environments, maintaining the sterility of the product. It can be widely used for sealing thermoplastic tubes on various single-use bag or tube assembly, achieving aseptic disconnection.
Features
• Fully automatic operation with duplex stain less steel heating plates for fast preheating and tube sealing.
• Simplified UI design with a 5" high-definition touchscreen for real-time process monitoring.
• Compatible with thermoplastic tubing with an outer diameter of 6.4–25.4 mm (1/4"–1").
• Larger tube contact area enhances heat stability, with three adjustable wall thickness levels for optimized sealing.
• Allows users to set different heat-sealing parameters within the supported wall thick ness range to accommodate various brands of TPE thermoplastic tubing.
• Equipped with Emergency Stop Button for safety
Operation Principle
The AbioSealer M500 thermoplastic tube sealer is equipped with two heating plates (upper and lower). The tubing is placed between the heating plates, which press and heat the tube. Under high temperature and pressure, the inner walls of the tube fuse together. After cooling, the tube is sealed, and it can be cut at the sealed midpoint using scissors for separation.
Ordering Information
